Robinia Nest Swing with Steel Crossbar – Ø1.2 m Nest Seat for Schools & Parks
Nest swing with Robinia legs, a steel crossbar and a Ø1.2 m rope nest seat for shared swinging. Ages 3+, 1.5 m free-fall height. Schools and parks.
Overview
A single-bay nest swing with four Robinia legs and a 3.14 m steel crossbar on steel mounting plates. The Ø1.2 m rope nest lets several children swing together, or one child sit or lie back and rock, giving calming vestibular movement and building core strength, balance and cooperation. The legs are set about 90 cm deep in concrete. The free-fall height is 1.5 m, so the swing needs a 26.5 m² safety zone with impact-absorbing surfacing: EN 1177 synthetic surfacing or 300 mm of loose fill. It suits schools, parks and natural play areas for ages 3+, and we supply and install it with our own teams.
- Product type: Single-bay nest swing with steel crossbar
- Functions: Group swinging, sitting or lying play, vestibular movement, balance and core strength
- Safety zone: 26.5 m²
- Free-fall height: 1.5 m
- Users: Recommended age 3+
- Nest seat: Ø1.2 m rope nest with chains and shackles on two swing suspensions
- Legs: Four Robinia posts, Ø14–16 cm, 3.6 m long
- Crossbar: Steel, 3.14 m long, with steel mounting plates
- Fixings: 16 mm threaded rods with welded nuts, washers and plastic caps; 12 x 90 mm coach screws
- Foundations: Posts set about 90 cm deep with a concrete foundation
- Weight: 320 kg in total; heaviest part 60 kg
- Surfacing: Impact-absorbing surfacing across the whole safety zone: EN 1177 synthetic surfacing tested to 1.5 m, or 300 mm of bark, woodchip, sand or gravel
- Morti ref.: MSP1045JJ
Specification
Certified to the relevant BS EN standard — full details in the product description and data sheet
Safety & surfacing
We'll match the safety surfacing to this item's free-fall height, your site and your budget, and include it in your quote. Where impact-absorbing surfacing is needed, it meets EN 1177. Annual inspection is recommended for school and public installations.
Downloads
Need CAD files or a site-specific layout? Ask us and we'll send them over.
Get a free design & budget price
Tell us your site size and age group and we'll send a layout, surfacing options and a budget price — usually within one working day.
